solved Overriding lightbox2 options in a template

SteveX
SteveX
@ultrajam
7 years ago
2,584 posts
I'm trying to show long and tall, scrollable images in lightbox2. It defaults to images resized to fit the screen.

Lightbox2 documentation says that you should be able to alter that by changing the script options like this:
<script>
    lightbox.option({
      'fitImagesInViewport': false
    })
</script>
http://www.lokeshdhakar.com/projects/lightbox2/

I can't get that to work either with the jamroom version (v2.7.1) or the current version (v2.9.0) of lightbox2.

If I use the github unminified v2.9.0 rather than the jamroom minified v2.7.1, add the if($("#lightbox").length == 0) { ... } lines, and change the defaults in the script it works how I want, but I'd like to just change the options in the template.

Any idea how I can do that?

Thanks :)


--
¯\_(ツ)_/¯ Education, learning resources, TEL, AR/VR/MR, CC licensed content, panoramas, interactive narrative, sectional modules (like jrDocs), lunch at Uni of Bristol. Get in touch if you share my current interests or can suggest better :)

updated by @ultrajam: 05/31/17 09:58:24AM
michael
@michael
7 years ago
7,719 posts
The flow:
* jrCore registers the file lightbox-2.7.1.min.js for inclusion
* That file has been changed from the original to include a wrapper
if($("#lightbox").length == 0) {
// the lightbox code ....
}
"If the lightbox hasnt been setup already in the #lightbox div, then set it up"

That's a point that could be tweaked. add a div #lightbox FIRST so that this code never fires, then put your own lightbox code in place.

--
Seams like the issue is lightbox.options is not defined. when I try to run lightbox.options from the console, its not there.

Might be that it is there, but on a different variable name.
Might be that it was defined inside a function so is not available in the global namespace.

Trying to find a way to access it now.
michael
@michael
7 years ago
7,719 posts
Looks like the best solution is for jrCore to update to v2.9.0
SteveX
SteveX
@ultrajam
7 years ago
2,584 posts
Thanks Michael.

Does that work for you with 2.9.0? I tried replacing the script, but still couldn't set the option in the template.

The only way I could get the result was to edit 2.9.0 to change the default.


--
¯\_(ツ)_/¯ Education, learning resources, TEL, AR/VR/MR, CC licensed content, panoramas, interactive narrative, sectional modules (like jrDocs), lunch at Uni of Bristol. Get in touch if you share my current interests or can suggest better :)
michael
@michael
7 years ago
7,719 posts
Replace the part inside the
if($("#lightbox").length == 0) {
// replace here with the minified version of 2.9.0 lightbox.min.js
}

That is in our codebase now for jrCore 6.1.0. Unless it causes issues it will be in the next major release.
SteveX
SteveX
@ultrajam
7 years ago
2,584 posts
I think I have that already, how are you setting the options in the template?


--
¯\_(ツ)_/¯ Education, learning resources, TEL, AR/VR/MR, CC licensed content, panoramas, interactive narrative, sectional modules (like jrDocs), lunch at Uni of Bristol. Get in touch if you share my current interests or can suggest better :)
michael
@michael
7 years ago
7,719 posts
yes, working for me.

/lighbox-2.9.0.min.js
/**
 * Lightbox v2.9.0
 * by Lokesh Dhakar
 *
 * More info:
 * http://lokeshdhakar.com/projects/lightbox2/
 *
 * Copyright 2007, 2015 Lokesh Dhakar
 * Released under the MIT license
 * https://github.com/lokesh/lightbox2/blob/master/LICENSE
 */
if ($("#lightbox").length == 0) {
}
Then altered the include.php for jrCore to replace the 2.7.1 version, so that code above exists in the page.

Then I opened:
http://yoursite.com/admin/gallery/tall-images/all

clicked the lightbox. The very tall image was shown shrunk to fit the screen vertically.

I changed:
/modules/jrGallery/templates/item_gallery.tpl from this
                <div class="gallery_lightbox">
                    <a href="{$jamroom_url}/{$murl}/image/gallery_image/{$_items[0]._item_id}/1280" data-lightbox="images" title="{$_items['0'].gallery_alt_text}">{jrCore_icon icon="search2"}&nbsp;&nbsp;<h3>{jrCore_lang module="jrGallery" id="37" default="View images in Lightbox"}</h3></a>
                </div>
to this
                <div class="gallery_lightbox">
<script>
    lightbox.option({
      'fitImagesInViewport': false
    })
</script>
                    <a href="{$jamroom_url}/{$murl}/image/gallery_image/{$_items[0]._item_id}/1280" data-lightbox="images" title="{$_items['0'].gallery_alt_text}">{jrCore_icon icon="search2"}&nbsp;&nbsp;<h3>{jrCore_lang module="jrGallery" id="37" default="View images in Lightbox"}</h3></a>
                </div>
Then clicked the VIEW ALL IMAGES IN LIGHTBOX again. This time the image filled the screen horizontally and overlapped it vertically. Not really evident that it was in a lightbox, but I believe thats the goal.
michael
@michael
7 years ago
7,719 posts
The result.
big.jpg  •  80KB

normal.jpg  •  59KB

SteveX
SteveX
@ultrajam
7 years ago
2,584 posts
Thank you Michael, I'm at the end of the day here so I'll give that a try tomorrow. :)


--
¯\_(ツ)_/¯ Education, learning resources, TEL, AR/VR/MR, CC licensed content, panoramas, interactive narrative, sectional modules (like jrDocs), lunch at Uni of Bristol. Get in touch if you share my current interests or can suggest better :)
SteveX
SteveX
@ultrajam
7 years ago
2,584 posts
Thanks Michael, that works perfectly.


--
¯\_(ツ)_/¯ Education, learning resources, TEL, AR/VR/MR, CC licensed content, panoramas, interactive narrative, sectional modules (like jrDocs), lunch at Uni of Bristol. Get in touch if you share my current interests or can suggest better :)
michael
@michael
7 years ago
7,719 posts
:)
